LM1458 LM1558 Dual Operational Amplifier IC

The LM1458 and LM1558 are general-purpose dual operational amplifier ICs designed for low-power analog signal applications. Each IC contains two independent op-amps with a shared bias and power supply, offering stable performance without the need for external frequency compensation. These devices support wide common-mode and differential voltage ranges, making them ideal for laptop analog circuits, power sensing, audio filtering, and instrumentation. LM1558 supports an extended temperature range, while LM1458 is optimized for commercial temperature operation.

• Product Name :- LM1458 / LM1558 Dual Operational Amplifier IC
• Manufacturer :- Texas Instruments / Other OEMs
• Equivalent Models :- LM358 (Functionally different but similar use cases in low-power circuits)

Features :-

• No frequency compensation required

• Short-circuit protected outputs

• Low-power consumption

• No latch-up when input range exceeded

• Wide common-mode & differential voltage support

Temperature Range :-

• LM1458: 0°C to +70°C

• LM1558: −55°C to +125°C (Extended range)

Package :- PDIP-8 / SOIC-8 / TO-99

Main Use :- Analog processing, laptop sensing circuits, power feedback, audio
